Energy harvesting from jaw movement to power hearing aids On a weekly basis, hundreds of millions of users worldwide must replace the button cell batteries in their hearing aids. Unfortunately, batteries are a source of environmental waste, a financial burden and somewhat time-consuming and requiring good dexterity to change. What if hearing-aids could be self-powered? Researchers at École de Technologie Supérieure are investigating energy harvesting to power hearing aids. As alternatives to batteries, energy harvesting technologies are increasingly gaining interest. Energy harvesters, which are able to recover small amounts of energy from external sources such as solar power, thermal energy, or human body, are usually suitable for low power portable or wearable devices. Hearing aids are among wearable medical devices which have been substantially modified in recent years and are becoming less energy consuming. Therefore, energy harvesting could be successfully applied to them. In addition to hearing aids, other types of in-ear devices such as electronic hearing protectors and communication earpieces could also benefit from energy harvesting technologies. This research project to replace hearing aid batteries by energy harvesting technologies is important for Dr. Aidin Delnavaz, a postdoc researcher working on this project. It reminds him his grandmother who suffers from hearing loss and hardly goes anywhere without her hearing aids. "She always complained about her unit because of problems caused by batteries. Sometimes these hearing aids fail at parties, family evenings or during telephone conversation" explains Dr. Delnavaz. Energy harvesting technologies for hearing aids The researchers have started by considering different sources of energy. Since the user wears the hearing aid, one possible power source would be the user and another would be the user's environment. Several innovative ideas have been recently proposed to use energy harvesting to power hearing aids. Light, body heat, electromagnetic waves, speaker vibrations, and radio frequency waves are sources of energy which have been already proposed for this application. Among the patented technologies, a solar recharging system is the only commercially available product on the market. It is composed of a charger unit with photovoltaic panels for recharging hearing aid batteries. The solar recharging system is very useful for the people who live in the areas where access to electric power is limited or expensive. While the hearing aid solar charger is an improvement, its battery power capacity is still limited and users must always rely on a solar charger, which is cumbersome and inconvenient. Some disadvantages can be assumed for other above-mentioned inventions that place them in an unfavorable position. For example, using photosensitive surfaces directly on the shell of the hearing aid requires more exposed external sections in order for the photocell to produce electrical current when exposed to ambient light. In practice however, hearing-aid users frequently request that the device be completely in the ear canal (CIC), that is, not visible from the outside: this reduces sunlight exposure to the point of discouraging the use of solar power for hearing aids. The main drawback of the thermoelectric system is that its thermal efficiency is highly influenced by ambient temperatures and radically drops in warmer environment. In case of energy harvesting from ambient radiations such as electromagnetic or infrared, their fundamental dependency upon the amount of energy available in the area of application significantly restricts their widespread usage. Ear canal dynamic motion The challenge of this project was to find a source of energy close to the ear canal to recharge the hearing aid. The ear canal is a dynamic environment. Indeed, opening the mouth contracts the face muscles and pulls the lower jaw down. Since the lower jaw is articulated to the head very close to the ear canal, its displacement deforms the soft tissue of the ear canal wall. Therefore, in each cycle of opening and closing the mouth, the ear canal deforms and then returns to its pre-deformed shape. This cycle occurs thousands of times during a day while chewing, eating or speaking and can be considered as a source of energy for hearing aids. The magnitude of ear canal deformation varies among individuals. We could measure it by comparing 3D images of ear impressions at two extents of the jaw excursion: open jaw and closed jaw. An experimental setup has been subsequently developed to measure the energy capacity of the ear canal dynamic motion and its capability to power hearing aids. The instantaneous power and the total energy produced by the ear canal dynamic motion during eating a medium size hamburger was measured. It is estimated that approximately 7mJ of energy per day is available from ear canal dynamic motions. This amount of energy can power a 1mW-hearing aid for more than 2 hours. Energy harvester The objective of the invention is to provide an in-ear technology for harvesting energy from the ear canal dynamic motions in order to power electronic circuits of hearing aids. Therefore, the desirable hearing device must be capable of being adapted to be placed inside the ear canal and having the contour of the ear canal wall. Fortunately, Sonomax Technologies Inc., a Quebec company specialized in hearing protection technologies and the industrial partner of the laboratory at ÉTS, has a patented technology based on inflatable earpieces to make a pair of custom-fitted earplugs only in 5 minutes. An advantage of our invention is integrating the energy harvesting module into this custom-fitted earpiece to provide a platform in which the required electronic components (for example a microphone, a digital signal processor and a speaker in case of the hearing aid) can be added to form a custom-fitted self-powered in-ear device. Another advantage is that the energy harvesting module is essentially transparent to the user of the in-ear device, that is, there is no electrical connection extending out from the in-ear device, no battery to periodically replace, no significant weight added to the in-ear device, etc. Also, the energy harvester device allows the electronic components to be powered on purpose by a jaw-joint activity, such as chewing gum, eating a solid meal, etc. In one embodiment of this invention, the energy harvesting module consists of a flexible piezoelectric film. It is formed in a hollow cylindrical shape and is adapted for being embedded inside the settable area of the in-ear device between a rigid core and the sheath. The settable area receives silicon medical rubber that remains generally flexible once set so as to transmit the dynamic motion of the ear canal wall to the energy harvesting module. The film electrodes are connected to a power management unit which is responsible to receive produced charges, store them and supply the power demanded by the electronic components. Source and top image: École de Technologie Supérieure Read more at: http://www.energyharvestingjournal.com/articles/energy-harvesting-from-jaw-movement-to-power-hearing-aids-00006690.asp?sessionid=1
